Design and Installation

Do you have CAD details or spec sheets?

Our design guides and spacing guides are available to download on our website.

How far apart do I hang each rack?

Spacing your racks depends on whether you want to save floor space, wall space, or a bit of both. We've created a handy Wall Placement Guide to help. Save Floor Space. If you want to save floor space, you will need to hang your racks further apart so

What size masonry drill bit do I need for installing?

Please visit our Installation Advice page for detailed instructions. As metric fixings don't always have an exact drill bit size match in various regions, if you are unsure we advise you to take the wall plugs provided with your rack to your local ha

How many bolts do I need to install a rack?

At the most, you will only need to use 4 - 2 for the top and 2 for the bottom. Steadyracks cannot be fixed to any fragile surface including drywall, gyprock, plasterboard etc. They must be fixed to structurally sound surfaces capable of taking the we

Can I mount the Steadyrack onto the side of a van?

Steadyracks are designed for indoor storage, such as garages and sheds. Our position is we advise not to do this, however using Steadyracks to transport bikes is possible and some customers have had success in using Steadyracks for this in the past.

What if my studs aren't where I want to put my racks?

You can fix rails across the studs at your preferred mounting height and then you can space your racks along the rails. Another option is to fix a sheet of plywood (10-13mm, or 1/2 inch thick) across the top of your wall lining or studs and then scre

Can I install my Steadyrack to Drywall, Plasterboard or Gyprock?

No. Steadyracks can be installed into any structurally sound vertical surface.It is NOT recommended that you install Steadyracks into Plasterboard or Drywall (also known as Gyprock). Fixing to Drywall, Plasterboard or Gyprock alone voids our warranty

Where can I install my racks?

Steadyracks can be installed into any structurally sound vertical surface. Fixings are provides for installing to Timber or Masonry (brick/concrete). If you wish to install the rack to any other type of surface, such as steel, you will need to purcha

Do I need to install the rear wheel bracket/rest?

We recommend installing the rear wheel bracket/rest with your Steadyrack bike rack, but if circumstances restrict you from installing it, the rack will still perform as required. You may find that your rear wheel moves more than usual without the res

Can the back wheel touch the ground when stowed in the rack?

Ideally no. The bike should be suspended above the floor to allow it to freely pivot. Bikes will come in different lengths and therefore different mounting heights which is why we suggest measuring your bikes first by following our installation guide

What height can I mount my racks at?

The height that you install your Steadyrack bike rack will vary depending on the bike. As all bikes are different sizes, ideally you want to install the rack to suit each specific bike. Our installation advice page and guide give detailed instruction

Can I install them outside?

In order to preserve your warranty, unfortunately, the answer is no. If you install your racks in an environment where they will be directly exposed to the elements, it will void our warranty. In doing so, your racks will show signs of rusting and th

Can I mount a tandem bike in a Steadyrack?

It is possible to install a tandem bike in a Steadyrack. However, the rack will need to be mounted higher to allow for the length of the tandem bike. You also need to ensure that the tandem bike doesn't exceed the maximum weight limit of the rack you

How secure have you made the folding bar and can it be latched to the frame providing a high degree of security?

Installing your Steadyrack using tamper proof bolts will provide a higher degree of security to prevent theft. It is also important that you do not rely on the rack arms when using a D Lock and Cable/Chain system, as the bolts holding these to the ra

What are the racks made from?

The Classic Range racks are made from chrome plated steel and the ProFlex Range racks are made from black nickel coated steel.

Are your products made from recycled products?

Our racks are not made from recycled products, however, all of our racks are made from recyclable materials as well as all of our packaging.

Why are your racks made in China/India?

Steadyrack is proudly Australian-owned and designed and we manufacture our racks in various locations, including China and India.We have tried to find an effective way to manufacture our products locally, however, to ensure we continue to maintain ou

What is the space between the two horizontal holes on the mounting plate?

The two horizontal holes are used for masonry installation, and are 6.5cm (2.56") apart, centre to centre.

What is the distance between the two vertical holes on the mounting plate?

The vertical holes are for timber/stud installations, and are 2.5cm (0.98") apart, centre to centre.

Can I install my Steadyrack to steel?

Yes, you can install Steadyrack bike racks onto steel surfaces. We recommend speaking to your local hardware store to source the appropriate fixings as they will vary depending on the type of steel that you are installing into, and the kit included w

What comes in the box with a Steadyrack bike rack?

1 x Rear Tire Rest- Please note, the ProFlex SteadyRest comes with a mounting plate. The Classic Range Rear Tire Rest comes individually. 1 x Installation kit with fixings for masonry and timber installs. 2 x Black End Caps- Please note, the ProFlex

How far out will my bike protrude when pivoted?

There is no specific measurement for this as each bike is different, but the best way to determine a rough estimate is to measure the widest part of your bike, normally the handlebars or pedals, and that will give you a guide as to how far the bike w
